UXL-20SC Xe 2000W Ushio 5001434
Cross Ref: XENON:
XBO 2000w/HS XL OFR Osram
XM2000HS/R ASL
YXL-20SC YXL-20SCFS Yumex
UXL-30SC Xe 3000W Ushio 50001079
LTIX-2000W-HS LTI
3K D130177 Strong 3130221 3130223 3130284
CXL-20SC
CXL-2000w-HEHS
SQP-SX20002 SX 20001 Superior Q
LTIX-2000W-HEHS
XH2000/HS
XQ2KW
LIN-XQ2KW
TBS2000W/HS
CH2000HS
Cross Ref: DIGITAL XENON:
XBO 2000w/DHS Osram
XD2000HS/R DIGITAL ASL
DXL-20BA
DXL-20BA/L
XDC-2001B
XENON SHORT ARC - UXL
Code- Lamp Desc- Amp- Volts- MOL(mm)- LCL(mm)- Dia(mm)- Arc Gap(mm)- Life(h)
UXL-20SC, Xe 2000W 110A 30v 342mm 147mm 60mm 6mm 1500hr
Quantity per case: 1
Fixtures used in:
- Barco DP 90
- Barco DP 100
- DP-3000
- Cinemeccanica ZX4000H
- IMAGINE PRO LIN-XQ3KW Xenon Lamp
- Lycian 1292 STUBBY ST
- Lycian 1293 X3K
- Lycian 1294 Super Arc 4K
- Lycian 1295 ELT
- NEC Model Starus NC1600
- NEC NC1600C
- NC2500S
- NEC NC2000C
- NC3200S
- NC3240S
- SONY SRX series
- Strong Super 80 4000-02 40000-04
- Syncrolite
- Space Cannon 30Kw
- Space Cannon SPL-3000
- SynchroLite Entertainment Technology SX3K-2
- XQ3KW
- Gladiator IV
- STRONG SUPER TROUPER II
- Super Trouper 2
- STRONG SUPER TROUPER III
- Super Trouper 3
- Projector Models:
- NEC NC 1600C
- NC 2000C
- NC 2500C
- Concert Touring
- Theatrical Events
- Sports Events
- Special Venues
XENON SHORT ARC - UXL
Code- Lamp Desc- Amp- Volts- MOL(mm)- LCL(mm)- Dia(mm)- Arc Gap(mm)- Life(h)
5001434 UXL-20SC, Xe 2000W 85 29 342 147 60 5.5 2400
5001077 UXL-25SC, Xe 2500W 90 28 342 147 60 6 1500hr
5001079 UXL-30SC, Xe 3000W 110 30 342 147 60 6 1500
5000631 UXL-40SC, Xe 4000W 150 29 410 174.5 70 7 1200
5000943 UXL-60SC, XE6000W 170 37 433 176 80 9 600hr
5000634 UXL-70SC, Xe 7000W 170 42 433 171 80 10 500hr
XENON Foot Notes
- DHP = Digital High Performance (Barco Projectors) Long Life Version
- DHS = Digital High Performance Short (Barco Projectors)
- DTP = Digital Threaded Pin (Christie Projectors)
- DTS = Digital Threaded Pin Super Performance (Christie Projectors)
- HPN = High Performance NEC
- HPS = High Performance Sony
- S = Short
- C = Base with Cable
- H = Suitable for horizontal operation
- OFR = Ozone Free
- s (Operating Position) = Vertical, base down
- p (Operating Position) = Horizontal
This lamp has positive pressure even when cold. Please read safety/warning instructions before using this lamp.
Distance a is from end of base to the respective electrode tip (cold) - see lamp drawing.
With vertical operating position: anode( ) on top.
